日本kyoto PH-47牙科造影頭模專為具有內部結構的最先進的合成牙齒的口外（全景）造影術而設計。可移動的下巴和舌頭允許各種應用程序的培訓和研究。

日本kyoto PH-47牙科造影頭模特征：
每顆牙齒分別建模并具有三層結構的牙釉質，牙本質和牙髓腔。
每個硬組織（牙釉質，牙本質，皮質骨和松質骨）具有特定的HU值和X射線吸收率。
大白鯊和舌頭是可拆卸的，以允許進入口腔，咽腔和上頜竇?？梢栽谶@些空腔中設置檢查器或模擬損傷或殘留物。
頸動脈被制備成流明以適應模擬鈣化。
培訓技能和QA應用程序
口外（全景）放射照相
口內X線攝影*
牙科CT
頭影和其他頭部X光片
*閉口位

日本kyoto PH-47牙科造影頭模解剖
合成顱骨有鼻腔，上頜竇，舌骨，下頜牙槽和上頜牙槽; 頸椎和舌骨，牙釉質，牙本質和牙髓腔。
舌，口腔，咽腔和頸動脈
規格

日本kyoto PH-47牙科造影頭模套裝包括：
1個主要頭部單位
1上顎（牙槽骨）
1下頜（牙槽骨）
1個舌頭
1個固定座（含螺絲）
1個三腳架
1個鋁制儲物箱

Dental Radiography Head Phantom - PH-47 - Kyoto Kagaku

Dental Radiography Head Phantom is designed for extra-oral (panoramic) radiography featuring state-of-the-art synthetic teeth with internal structures. Removable jaws and tongue allow a variety of application for training and research.

Features:
Each tooth is individually modeled and has a three-layer structure of enamel, dentin and pulp cavity.
Each hard tissue (enamel, dentin, cortical bone and cancellous bone) has a particular HU number and X-ray absorption rate.
Jaws and tongue are detachable to allow access to the oral cavity, pharyngeal cavity and maxillary sinus. Censors or simulated lesions or residue can be set in these cavities.
Carotid arteries are prepared as lumens to accommodate simulated calcifications.
Training Skills and QA Applications
Extra-oral (Panoramic) radiography
Intraoral radiography*
Dental CT
Cephalography and other head radiography
*with closed mouth position

Anatomies
Synthetic skull with nasal cavity, maxillary sinus, hyoid bone, mandible alveolar, and maxillary alveolar; cervical vertebrae and hyoid bone, teeth with enamel, dentin and pulp cavity.
Tongue, oral cavity, pharyngeal cavity and carotid arteries
Specifications

Set Includes:
1 main head unit
1 upper jaw (alveolar bone)
1 lower jaw (alveolar bone)
1 tongue
1 fixation base (including screws)
1 tripod
1 aluminum storage case
